Power Signal Connector 20A 3 Pin IP67 Electrical Signal Waterproof Connector With Dust Cover
Features:
1: With multi-core design to fit with different industrial needs.
2: Design snap lock ensures stable and security firm.
3: Humanization design achieved blind operation.
4: Both soldering and crimping are available.
5: Socket and internal made of zinc alloy,with well protected electromagnetic and radio frequency interference.
6: Gold-plating; high strength corrosion resistance and electrical conductivity.
7: Shell made of material PBT,stable electrical performance,high strength and resistance to pressure,high temperature resistance,anti-explosion,anti-corrosive.
8: Both cable connector to cable connector and cable connector to panel mounting are available.
9: IP65 to IP67 when mated.
Parameter:
| Pin Number | 3 pins |
| Rated Voltage | 500V |
| Rated Current | 20A |
| Wire Guage | 3*2.0mm2 |
| Pin Diameter | 2.0mm |
| Waterproof Level | IP67 |
| Connection | Bayonet, Snap Lock |
| Contact Resistance | ≤5mΩ |
| Wire OD | 11.5mm |
| Seal O-ring | Silicon |
| Termination | Screw |
| Working Temperature | -40℃~105℃ |
| Shell Material | Nylon PA66 |
| Contact Pin Material | Brass |
| Finish | Silver |
Application:
Stage equipment - The smart grid
Medical equipment - Server
Solar energy equipment - Ship equipment
Electric power equipment - Vehicle equipment
Communications equipment - Heavy machinery
Service
Shenzhen HuaYi-FaDa Technology is a professional manufacturer for waterproof connector for over 12 years. We can provide you with:
● Independent research and development
● Cable and hardware production
● Injection molding and mould making
● Perfect assembly workshop
With us, you can get the best goods in shortest time.
WHY US?
1.We can do the designs according to the customers' requirement
2.We can open customers'own mould as per their requirement
3.We can offer you connectors with high quality & reasonable price
4.We can offer your a good after-sell service
5.We have strong professional design team
6. Prompt delivery. small order is welcome
7.Rich experience for over 12 years
8.Comprehensive R&D testing and the line of highly automatic production make our products high reliability and high operational capability.
